| General | |
|---|---|
| Frequency Range | VHF: 136â174MHz / UHF: 400â480MHz |
| Channel Capacity | 64 Channels (4 Zones) |
| Channel Spacing | Analog: 25/12.5KHz, Digital: 12.5KHz |
| Operating Voltage | DC 7.4V |
| Battery Capacity | 2500mAh Li-ion |
| Battery Life | Approx. 15 Hours (5-5-90 Duty Cycle) |
| Operating Temperature | -20°C to +60°C |
| Frequency Stability | ±2.5ppm |
| Antenna Impedance | 50Ω |
| Dimensions (HÃWÃD) | 113 Ã 52 Ã 32 mm (without antenna) |
| Weight | 261g (with antenna & battery) |
| Transmitter | |
| RF Power Output | 10W / 5W (Selectable) |
| Modulation (Analog) | 11KФF3E @12.5KHz / 16KФF3E @25KHz |
| Modulation (Digital) | 7K60FXD (Data), 7K60FXE (Voice+Data) |
| Spurious Emissions | -36dBm <1GHz, -30dBm >1GHz |
| FM Noise | 40/45dB |
| Audio Distortion | â¤5% |
| Modulation Limiting | ±2.5KHz @12.5KHz, ±5.0KHz @25KHz |
| Audio Response | +1 to -3dB |
| Vocoder | AMBE++ |
| Digital Protocol | ETSI TS102 361-1,-2 |
| Receiver | |
| Sensitivity (Analog) | â¤0.3μV (12dB SINAD) |
| Sensitivity (Digital) | â¤0.30μV @BER 5% |
| Selectivity | â¥60dB / 65dB |
| Spurious Rejection | â¥60dB |
| Intermodulation | â¥60dB |
| Signal-to-Noise Ratio | 40/45dB |
| Rated Audio Power | 1.5W |
| Audio Distortion | â¤3% |
| Conducted Spurious Emission | ï¼-57dBm |
